Matrix Differentiation (involving Hadamard products)
How do you expand this frobenius form?Inequality involving traces and matrix inversionsDerivative of determinant of symmetric matrix wrt a scalarPartial derivative of weighted matrix factorization?Derivatives involving inner product and Hadamard productDerivative of trace functions using chain ruleDerivative of Frobenius norm of Hadamard ProductHelp with matrix derivativeFrobenius Norm of Hadamard Product and TraceDerivative of Hadamard product with respect to matrix
$begingroup$
I am trying to differentiate over the following Frobenius Norm: $$Phi =||A-(Bcirc C)D ||^2_F$$
with respect to B, C, D respectively, i.e.:
$$frac{partial Phi}{partial B}, frac{partial Phi}{partial C},frac{partial Phi}{partial D}$$
After expending the norm and writing it in the trace form, it becomes:
$$Phi = tr(A^TA) -tr(A^T(Bcirc C)D )-tr(D^T(B^Tcirc C^T)A)+tr(D^T(B^T circ C^T)(B circ C)D) $$
(please correct me if I did the expansion wrong)
I've tried to write them elements by elements and checked out the whole matrix cookbook.
Since there's a hadamard product involving in the equation, I got completely confused of differentiating the last three terms.
Could anyone help me out please? I appreciate a lot.
linear-algebra matrices derivatives matrix-calculus hadamard-product
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
$endgroup$
add a comment |
$begingroup$
I am trying to differentiate over the following Frobenius Norm: $$Phi =||A-(Bcirc C)D ||^2_F$$
with respect to B, C, D respectively, i.e.:
$$frac{partial Phi}{partial B}, frac{partial Phi}{partial C},frac{partial Phi}{partial D}$$
After expending the norm and writing it in the trace form, it becomes:
$$Phi = tr(A^TA) -tr(A^T(Bcirc C)D )-tr(D^T(B^Tcirc C^T)A)+tr(D^T(B^T circ C^T)(B circ C)D) $$
(please correct me if I did the expansion wrong)
I've tried to write them elements by elements and checked out the whole matrix cookbook.
Since there's a hadamard product involving in the equation, I got completely confused of differentiating the last three terms.
Could anyone help me out please? I appreciate a lot.
linear-algebra matrices derivatives matrix-calculus hadamard-product
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
$endgroup$
add a comment |
$begingroup$
I am trying to differentiate over the following Frobenius Norm: $$Phi =||A-(Bcirc C)D ||^2_F$$
with respect to B, C, D respectively, i.e.:
$$frac{partial Phi}{partial B}, frac{partial Phi}{partial C},frac{partial Phi}{partial D}$$
After expending the norm and writing it in the trace form, it becomes:
$$Phi = tr(A^TA) -tr(A^T(Bcirc C)D )-tr(D^T(B^Tcirc C^T)A)+tr(D^T(B^T circ C^T)(B circ C)D) $$
(please correct me if I did the expansion wrong)
I've tried to write them elements by elements and checked out the whole matrix cookbook.
Since there's a hadamard product involving in the equation, I got completely confused of differentiating the last three terms.
Could anyone help me out please? I appreciate a lot.
linear-algebra matrices derivatives matrix-calculus hadamard-product
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
$endgroup$
I am trying to differentiate over the following Frobenius Norm: $$Phi =||A-(Bcirc C)D ||^2_F$$
with respect to B, C, D respectively, i.e.:
$$frac{partial Phi}{partial B}, frac{partial Phi}{partial C},frac{partial Phi}{partial D}$$
After expending the norm and writing it in the trace form, it becomes:
$$Phi = tr(A^TA) -tr(A^T(Bcirc C)D )-tr(D^T(B^Tcirc C^T)A)+tr(D^T(B^T circ C^T)(B circ C)D) $$
(please correct me if I did the expansion wrong)
I've tried to write them elements by elements and checked out the whole matrix cookbook.
Since there's a hadamard product involving in the equation, I got completely confused of differentiating the last three terms.
Could anyone help me out please? I appreciate a lot.
linear-algebra matrices derivatives matrix-calculus hadamard-product
linear-algebra matrices derivatives matrix-calculus hadamard-product
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
asked 2 days ago
Rio LiRio Li
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
asked 2 days ago
Rio LiRio Li
1
asked 2 days ago
Rio LiRio Li
1
1
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
New contributor
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
Rio Li is a new contributor to this site. Take care in asking for clarification, commenting, and answering.
Check out our Code of Conduct.
add a comment |
add a comment |
1 Answer
1
active
oldest
votes
$begingroup$
Define the matrices
$$eqalign{
X &= Bcirc C,quad Y=XD-A cr
}$$
Write the function in terms of these new variables.
Then find its differentials and gradients (in alphabetical order).
$$eqalign{
phi &= |Y|_F^2 = Y:Y cr
dphi &= 2Y:dY cr
&= 2Y:dX,D cr
&= 2YD^T:Ccirc dB cr
&= 2Ccirc(YD^T):dB cr
frac{partialphi}{partial B} &= 2Ccirc(YD^T) cr
}$$
Since $B$ and $C$ are indistinguishable
$$eqalign{
frac{partialphi}{partial C} &= 2Bcirc(YD^T) cr
}$$
Finally, the gradient wrt $D$
$$eqalign{
dphi &= 2Y:X,dD cr
&= 2X^TY:dD cr
frac{partialphi}{partial D} &= 2X^TY cr
}$$
NB: In several of the steps above, a colon is used as a convenient product notation for the trace, i.e. $$B:C = {rm Tr}(B^TC)$$
answered 2 days ago
greggreg
8,7751824
$endgroup$
$begingroup$
Thank you so much for your answer. It is very clear and understandable. This helps me a lot.
$endgroup$
– Rio Li
yesterday
add a comment |
