$begingroup$
I am using the following code to make a 3D vector plot.
VectorPlot3D[
x (1 - x) - x*y,
y (1 - y) + x*y - y*z,
z (1 - z) + y*z,
x, 0, 1.2,
y, 0, 1.2,
z, 0, 1.2,
Axes -> True, AxesLabel -> "x", "y", "z",
VectorColorFunction -> "Rainbow",
VectorScale -> 0.05, 0.7, None]
This makes a bunch of vectors, but the entire vector is colored. Is there a way I can use VectorStyle or another option to make each vector have a black outline, but have the inside of the area filled in with the appropriate color?
plotting
asked 1 hour ago
jeanquiltjeanquilt
1084
$endgroup$
add a comment |
$begingroup$
I am using the following code to make a 3D vector plot.
VectorPlot3D[
x (1 - x) - x*y,
y (1 - y) + x*y - y*z,
z (1 - z) + y*z,
x, 0, 1.2,
y, 0, 1.2,
z, 0, 1.2,
Axes -> True, AxesLabel -> "x", "y", "z",
VectorColorFunction -> "Rainbow",
VectorScale -> 0.05, 0.7, None]
This makes a bunch of vectors, but the entire vector is colored. Is there a way I can use VectorStyle or another option to make each vector have a black outline, but have the inside of the area filled in with the appropriate color?
plotting
asked 1 hour ago
jeanquiltjeanquilt
1084
$endgroup$
add a comment |
$begingroup$
I am using the following code to make a 3D vector plot.
VectorPlot3D[
x (1 - x) - x*y,
y (1 - y) + x*y - y*z,
z (1 - z) + y*z,
x, 0, 1.2,
y, 0, 1.2,
z, 0, 1.2,
Axes -> True, AxesLabel -> "x", "y", "z",
VectorColorFunction -> "Rainbow",
VectorScale -> 0.05, 0.7, None]
This makes a bunch of vectors, but the entire vector is colored. Is there a way I can use VectorStyle or another option to make each vector have a black outline, but have the inside of the area filled in with the appropriate color?
plotting
asked 1 hour ago
jeanquiltjeanquilt
1084
$endgroup$
I am using the following code to make a 3D vector plot.
VectorPlot3D[
x (1 - x) - x*y,
y (1 - y) + x*y - y*z,
z (1 - z) + y*z,
x, 0, 1.2,
y, 0, 1.2,
z, 0, 1.2,
Axes -> True, AxesLabel -> "x", "y", "z",
VectorColorFunction -> "Rainbow",
VectorScale -> 0.05, 0.7, None]
This makes a bunch of vectors, but the entire vector is colored. Is there a way I can use VectorStyle or another option to make each vector have a black outline, but have the inside of the area filled in with the appropriate color?
plotting
plotting
asked 1 hour ago
jeanquiltjeanquilt
1084
asked 1 hour ago
jeanquiltjeanquilt
1084
asked 1 hour ago
jeanquiltjeanquilt
1084
asked 1 hour ago
jeanquiltjeanquilt
1084
asked 1 hour ago
jeanquiltjeanquilt
1084
1084
add a comment |
add a comment |
1 Answer
1
active
oldest
votes
$begingroup$
You can use Graphics to define any shape for drawing the vectors. Something like this:
VectorPlot3D[x (1 - x) - x*y, y (1 - y) + x*y - y*z,
z (1 - z) + y*z, x, 0, 1.2, y, 0, 1.2, z, 0, 1.2,
Axes -> True, AxesLabel -> "x", "y", "z",
VectorColorFunction -> "Rainbow", VectorPoints -> 5, VectorScale -> 0.03, .7, None,
VectorStyle -> Graphics[EdgeForm[Black], Rectangle[-2, -.2, 0, .2],
Polygon[0, .5, Sqrt[3], 0, 0, -.5]]]
answered 58 mins ago
MelaGoMelaGo
3613
$endgroup$
$begingroup$
Thank you! This is exactly how I wanted the plot to look!
$endgroup$
– jeanquilt
32 mins ago
add a comment |
